Motor Side Drive - MSD
For linear units with drive journal w/o keyway to mount MSD belt drive
Designation | Select all | CAD | Compare | Get quote | Lead Time * | Carriage Length Lv (mm) | Dynamic Moment Mx (Nm) | Dynamic Moment My (Nm) | Dynamic Moment Mz (Nm) | Dynamic Load Capacity C (N) | Static Load Capacity C0 (N) | Max. Permissible Loads Forces Fpy (N) | Max. Permissible Loads Forces Fpz (N) | Max. Permissible Loads Moments Mpx (Nm) | Max. Permissible Loads Moments Mpy (Nm) | Max. Permissible Loads Moments Mpz (Nm) | Moved Mass (kg) | Max. Length Lmax (mm) | Max. Stroke (mm) | Min. Stroke (mm) |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
2 | 80 | 3220 | 450 | 900 | 49600 | 85000 | 10000 | 24610 | 1600 | 450 | 308 | 3.11 | 2200 | 2000 | 65 | |||
|
|
2 | 80 | 3220 | 450 | 900 | 49600 | 85000 | 10000 | 24610 | 1600 | 450 | 308 | 3.11 | 2200 | 2000 | 65 | |||
|
|
2 | 80 | 3220 | 450 | 900 | 49600 | 85000 | 10000 | 24610 | 1600 | 450 | 308 | 3.11 | 2200 | 2000 | 65 | |||
|
|
2 | 80 | 3220 | 450 | 900 | 49600 | 85000 | 10000 | 24610 | 1600 | 450 | 308 | 3.11 | 2200 | 2000 | 70 | |||
|
|
2 | 255 | 6445 | 8680 | 8680 | 99200 | 170000 | 20000 | 51540 | 3350 | 4550 | 1750 | 6.21 | 2200 | 1825 | 65 | |||
|
|
2 | 255 | 6445 | 8680 | 8680 | 99200 | 170000 | 20000 | 51540 | 3350 | 4550 | 1750 | 6.21 | 2200 | 1825 | 65 | |||
|
|
2 | 255 | 6445 | 8680 | 8680 | 99200 | 170000 | 20000 | 51540 | 3350 | 4550 | 1750 | 6.21 | 2200 | 1825 | 65 | |||
|
|
2 | 255 | 6445 | 8680 | 8680 | 99200 | 170000 | 20000 | 51540 | 3350 | 4550 | 1750 | 6.21 | 2200 | 1825 | 70 |
*Green: Normally in stock, contact us for current status. Blue: Contact us for delivery time.
Designation | Select all | CAD | Compare | Get quote | Carriage version | Dynamic Load Capacity C (N) | Static Load Capacity C0 (N) | Dynamic Moment Mx (Nm) | Dynamic Moment My (Nm) | Dynamic Moment Mz (Nm) | Max. Permissible Loads Forces Fpy (N) | Max. Permissible Loads Forces Fpz (N) | Max. Permissible Loads Moments Mpx (Nm) | Max. Permissible Loads Moments Mpy (Nm) | Max. Permissible Loads Moments Mpz (Nm) |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
S2 (S) | 99200 | 170000 | 6440 | 49.6 × A (mm) | 49.6 × A (mm) | 20000 | 49230 | 3200 | 24.6 × A (mm) | 10.0 × A (mm) | |||
|
|
S2 (S) | 99200 | 170000 | 6440 | 49.6 × A (mm) | 49.6 × A (mm) | 20000 | 49230 | 3200 | 24.6 × A (mm) | 10.0 × A (mm) | |||
|
|
S2 (S) | 99200 | 170000 | 6440 | 49.6 × A (mm) | 49.6 × A (mm) | 20000 | 49230 | 3200 | 24.6 × A (mm) | 10.0 × A (mm) | |||
|
|
S2 (S) | 99200 | 170000 | 6440 | 49.6 × A (mm) | 49.6 × A (mm) | 20000 | 49230 | 3200 | 24.6 × A (mm) | 10.0 × A (mm) | |||
|
|
S2 (L) | 99200 | 170000 | 6440 | 49.6 × A (mm) | 49.6 × A (mm) | 20000 | 49230 | 3200 | 24.6 × A (mm) | 10.0 × A (mm) | |||
|
|
S2 (L) | 99200 | 170000 | 6440 | 49.6 × A (mm) | 49.6 × A (mm) | 20000 | 49230 | 3200 | 24.6 × A (mm) | 10.0 × A (mm) | |||
|
|
S2 (L) | 99200 | 170000 | 6440 | 49.6 × A (mm) | 49.6 × A (mm) | 20000 | 49230 | 3200 | 24.6 × A (mm) | 10.0 × A (mm) | |||
|
|
S2 (L) | 99200 | 170000 | 6440 | 49.6 × A (mm) | 49.6 × A (mm) | 20000 | 49230 | 3200 | 24.6 × A (mm) | 10.0 × A (mm) |
Designation | Select all | CAD | Compare | Get quote | Max. Travel Speed (m/s) | Max. Rotational Speed (rev/min) | Max. Drive Torque Ma (Nm) | Lead Constant (mm/rev) | No Load Torque Carriage S (Nm) | No Load Torque Carriage L (Nm) | Ball Screw (d x l) | Max. Repeatability Precision Standard ISO7 | Max. Repeatability Precision ISO5 | Dynamic Load Capacity BS Ca (N) | Max. Axial Load Fx (N) | Planar Moment of Inertia ly (cm⁴) | Planar Moment of Inertia lz (cm⁴) |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
0.18 | 2150 | 16,7 (w. keyway), 16,7 (w.o keyway) | 5 | 0.60 × nc | 0.70 × nc | 32 × 5 | ± 0.02 | ± 0.01 | 18850 | 18850 | 417.4 | 3007.3 | |||
|
|
0.5 | 3000 | 27,3 (w. keyway), 52,3 (w.o keyway) | 10 | 0.70 × nc | 0.80 × nc | 32 × 10 | ± 0.02 | ± 0.01 | 33400 | 29600 | 417.4 | 3007.3 | |||
|
|
1 | 3000 | 27,3 (w. keyway), 52,3 (w.o keyway) | 20 | 0.75 × nc | 0.85 × nc | 32 × 20 | ± 0.02 | ± 0.01 | 29700 | 14800 | 417.4 | 3007.3 | |||
|
|
1.6 | 3000 | 27,3 (w. keyway), 52,3 (w.o keyway) | 32 | 0.80 × nc | 0.90 × nc | 32 × 32 | ± 0.02 | ± 0.01 | 35150 | 9240 | 417.4 | 3007.3 | |||
|
|
0.18 | 2150 | 16,7 (w. keyway), 16,7 (w.o keyway) | 5 | 0.60 × nc | 0.70 × nc | 32 × 5 | ± 0.02 | ± 0.01 | 18850 | 18850 | 417.4 | 3007.3 | |||
|
|
0.5 | 3000 | 27,3 (w. keyway), 52,3 (w.o keyway) | 10 | 0.70 × nc | 0.80 × nc | 32 × 10 | ± 0.02 | ± 0.01 | 33400 | 29600 | 417.4 | 3007.3 | |||
|
|
1 | 3000 | 27,3 (w. keyway), 52,3 (w.o keyway) | 20 | 0.75 × nc | 0.85 × nc | 32 × 20 | ± 0.02 | ± 0.01 | 29700 | 14800 | 417.4 | 3007.3 | |||
|
|
1.6 | 3000 | 27,3 (w. keyway), 52,3 (w.o keyway) | 32 | 0.80 × nc | 0.90 × nc | 32 × 32 | ± 0.02 | ± 0.01 | 35150 | 9240 | 417.4 | 3007.3 |
Designation | Select all | CAD | Compare | Get quote | Ball Screw (d x l) | Mass of Linear Unit (kg) | Mass Moment of Inertia (10⁻⁵ kg m²) | Planar Moment of Inertia ly (cm⁴) | Planar Moment of Inertia lz (cm⁴) | Moved Mass (kg) |
---|---|---|---|---|---|---|---|---|---|---|
|
|
32 × 5 | 15.4 + 0.031 × (Abs. Stroke + (nc - 1) × A) + 3.11 × (nc - 1) | 21.17 + 0.069 × (Abs. Stroke + (nc - 1) × A) + 0.20 × (nc - 1) | 417.4 | 3007.3 | 3.11 | |||
|
|
32 × 10 | 15.4 + 0.031 × (Abs. Stroke + (nc - 1) × A) + 3.11 × (nc - 1) | 21.76 + 0.069 × (Abs. Stroke + (nc - 1) × A) + 0.79 × (nc - 1) | 417.4 | 3007.3 | 3.11 | |||
|
|
32 × 20 | 15.4 + 0.031 × (Abs. Stroke + (nc - 1) × A) + 3.11 × (nc - 1) | 24.12 + 0.069 × (Abs. Stroke + (nc - 1) × A) + 3.15 × (nc - 1) | 417.4 | 3007.3 | 3.11 | |||
|
|
32 × 32 | 15.4 + 0.031 × (Abs. Stroke + (nc - 1) × A) + 3.11 × (nc - 1) | 29.04 + 0.069 × (Abs. Stroke + (nc - 1) × A) + 8.07 × (nc - 1) | 417.4 | 3007.3 | 3.11 | |||
|
|
32 × 5 | 23.8 + 0.031 × (Abs. Stroke + (nc - 1) × A) + 6.21 × (nc - 1) | 33.41 + 0.069 × (Abs. Stroke + (nc - 1) × A) + 0.39 × (nc - 1) | 417.4 | 3007.3 | 6.21 | |||
|
|
32 × 10 | 23.8 + 0.031 × (Abs. Stroke + (nc - 1) × A) + 6.21 × (nc - 1) | 34.59 + 0.069 × (Abs. Stroke + (nc - 1) × A) + 1.59 × (nc - 1) | 417.4 | 3007.3 | 6.21 | |||
|
|
32 × 20 | 23.8 + 0.031 × (Abs. Stroke + (nc - 1) × A) + 6.21 × (nc - 1) | 39.31 + 0.069 × (Abs. Stroke + (nc - 1) × A) + 6.29 × (nc - 1) | 417.4 | 3007.3 | 6.21 | |||
|
|
32 × 32 | 23.8 + 0.031 × (Abs. Stroke + (nc - 1) × A) + 6.21 × (nc - 1) | 49.12 + 0.069 × (Abs. Stroke + (nc - 1) × A) + 16.11 × (nc - 1) | 417.4 | 3007.3 | 6.21 |
